This PWM motor uses two high-voltage and low internal resistance MOS tubes, as well as the front-stage driver, with more stable performance. With digital tube display to display motor regulation duty cycle, upper and lower duty cycle limits, and frequency. Adopts a rotary knob for motor speed adjustment, turn left to decrease speed, and turn right to increase speed; short press it to control motor startsstops, and long press it to enter into setting mode.
Features:
High Power and More Stable: Uses two high-voltage and low internal resistance MOS tubes, as well as the front-stage driver, with more stable performance. Supports high voltage and high power.
Digital Tube Display: Support to display motor regulation duty cycle, upper and lower duty cycle limits, and frequency.
High Precise: The digital encoder adopts a rotary knob for motor speed adjustment, which is more precise than ordinary potentiometer adjustment, better consistency, and no drift.
Rotary Encoder: Turn left to decrease speed, and turn right to increase speed; short press it to control motor startsstops, and long press it to enter into setting mode.
Indicator Light: Equipped with a motor status indicator light that illuminates on startup and extinguishes on shutdown.
Motor Soft-starts Function: The current increases slowly when the motor starts, with no inrush current, does not damage the battery, effectively protects the motor, and prolongs its service lifespan.
Automatic Starts-stop: It is equipped with a startstop button. It can be controlled by an external switch to meet the customer's multiple control needs, more convenient.
Practical Scenarios: Used to generate square and rectangularwave signals to control direct current motors or stepper motor drivers; used for servo motors, stepper motors, electric grippers, replacing PLC pulses, and more. PULSE mode can control the number of pulses, which can control the number of turns of the stepper motor!
Wide Applications: Matching driver to realize dimming, speed control, control solenoid valves, etc., but can not directly drive the lamp motor solenoid valves and other loads.
Specifications:
Name: PWM Direct Current Motor
Material: plastics
Working voltage: 5-30VDC
Rated current: 5A, max 15A
Power: Max 150W
Working frequency: 1KHZ-99KHZ adjustable, 1KHZ steps, the default frequency of 20KHZ, accuracy of about 1percent
Duty cycle: 0-100percent , 1percent steps
Installation size: 39.3 * 76.5mm 1.55 * 3.01in
Item size: 79 * 48 * 27mm 3.11 * 1.89 * 1.06in
Item weight: 43g 1.52ounce
Package size: 110 * 65 * 50mm 4.33 * 2.56 * 1.97in
Package weight: 69g 2.43ounce
Packing List:
1 * PWM Direct Current Motor
